HFO-1336mzz(E)

2021-11-25 14:22

Product Description

Chemical Name Trans-1,1,1,4,4,4-Hexafluoro-2-butene
Synonyms HFO-1336mzz(E)
CAS # 66711-86-2
ELINCS # (EU) 811-213-0
Molecular Formula C4H2F6
Structure
Molecular Weight 164.05
Physical state Gas
Color Colourless
Odor Odorless
ODP(CFC-11 = 1) 0
GWP100(CO2 = 1) 26
Life Time (Days) 121
TWA(8-hr) 400 ppm

Physical & Chemical Properties

Chemical Name Trans-1,1,1,4,4,4-Hexafluoro-2-butene
Boiling Point(℃) 7.5
Melting Point(℃) <-20
Liquid Density(@20℃) 1.31
Gas Density(Air=1) 5.3
Vapor Pressure(@20℃) 163.52
Vapor Thermal Conductivity(@25℃,mW/m·K) 11.5
Critical Temperature(℃) 130.2
Critical Pressure(bar) 36.36
Critical Density (kg/m3) 489
Solubility(@20℃) 0.28
Flash Point(℃) Not applicable
Flammability(@21℃) Not applicable
Explosion Limit(%vol) Not applicable



Packing Specification

Cylinder Size Filling Weight
13.4 L 10 kg
926 L 1000 kg
24000 L 15000kg
